HERCULES 8
THE TALLEST TOWER: 8m!
Super frontal loading lifting tower. HERCULES Series, powerful and easy to use.
Uses: For lifting line array systems, trussing or LED screens.
Features:
- All HERCULES towers lift the load from the floor and are height adjustable.
- Made of aluminium.
- Available colour: Black.
HERCULES 8 LIFTING TOWER
Maximum height: 8m
Height folded: 1,99m
Maximum load: 300kg
Minimum charge: 25kg
Material: Aluminum alloy AL Si 6106 / T6
Workspace: 2,50 x 2,28m
Closed base area: 0,52 x 0,62m
Weight: 203kg
Winch: AL-KO Type OPTIMA 1150kg
Cable: Galvanized steel under EN 12385-4.
Maximum cable load: 2.870kg
Cable twisting resistance : 1.770N/mm²
Cable diameter: 6mm
Cable composition: 7x19+0
Security system: Inner pendulum and external trigger in sections.
Leg attachment: Safety pins
Bubble level: to vertically adjust the tower.
